This isn't a single project, but a collection of various tools I've created to aid with rapidly prototyping grid-based games.
The majority of the framework mostly consists of a variety of tools to implement different grid-based gameplay elements. Things such as target selection, movement, unit/environment interactions, combat, procedural generation, etc...
This also includes some basic editor tools that I use to quickly create units, tiles, and other data without having to leave the Unity editor. A lot of these systems will get there own articles in the future, but for now I'll just be posting a few screenshots and a brief description.

**Action System:**
One of the main components driving this prototype is an action system that implements the command pattern. This is one of the most useful patterns I've used lately, dependency injection and interfaces are a great way of keeping your code organized in the long run. More importantly however, it lets me queue up actions and events for multi-unit, turn-based gameplay. This lets me sort action execution via whatever priority system I like, "rewind" actions/turns, and implement more complex turn-based systems (like SMT's press-turn system for example). The current implementation isn't anything fancy, just an energy system that allows the player multiple actions per turn, and an enemy manager that queues up enemy actions once the player's turn has ended. The system is designed to be easy to extend, so in the future I might reuse it for more strategy oriented gameplay systems.

Grid prototype example 1: ![Prototype example 1](/grid1.gif)
Grid prototype example 2: ![Prototype example 2](/grid2.gif)
Grid prototype example 3: ![Prototype example 3](/grid3.gif)

**Data Editors:**
I needed an easy way to generate and edit game content. Serialized Objects are useful for storing data, but I wanted a more user-friendly option for creating it. Using the Odin serialization plug-in, I made a series of small editor tools that allow the user to create a variety of data objects through a single window. For this example, I made a player unit, enemy, tile, and attack editor window. It's a simple tool, but it allows me to add new content quickly and easily.

Data editor example 1: ![Data editor example 1](/data_editor1.png)
Data editor example 2: ![Data editor example 2](/data_editor2.png)
Data editor example 3: ![Data editor example 2](/attack_editor.png)

**Utility Classes:**
I separated particularly useful and recurring functionality into utility classes to use for multiple systems. A lot of the grid utility functions have to do with procedural generation, movement calculations, and other algorithms that are useful in isometric and cartesian coordinate grids. You can use them for most grid-based games, but they're especially useful for roguelikes and strategy games.

FPS grid example: ![FPS grid example](/fpsgrid.gif)

**Map generation:**
Map generation using cellular automata and binary space partitioning. Basically a map generator with a bunch of tweakable parameters that produces a tile-based map of 1's and 0's. After that you can add in different tile types and rulesets to populate the map as 2D tiles or 3D objects. Still working on mesh generation with occlusion culling but that's complex enough to warrant a seperate project.

**Djitskra maps:**
I also implemented Djisktra maps to populate the levels with items, enemies, and other things.
A huge advantage of using Djisktra maps is that they can also be used for AI purposes if you have a grid-based, turn-based game. Since each unit has it's own internal Djistkra map, it lets you easily add objective-based behaviours to units.
Below is a heatmap representation of an example Djistkra map for the player unit. The closer a tile is to the player, the brighter it appears. AI can independently choose to run away, chase, or even ignore the player unit depending on its internal state.
This is a really useful tool for handling procedural generation and AI for most grid-based games.
You can find a more in-depth example of the concept at: http://roguebasin.com/index.php/Dijkstra_Maps_Visualized

**Scene Switcher:**
While not exactly a "grid"-related tool, it helps me switch scenes in the Unity editor without having to rummage through all the project directories. Super simple implementation, but small quality of life editor tools help save huge amounts of time.
Scene switcher example: ![Scene switcher example](/scene_switcher.png)

https://github.com/GarcGustavo/DungeonAutomata/tree/main/_Project/Scripts

A suite of utility tools used to create grid-based games.

Grid utilities and editor tools


This is a dialogue system that uses scriptable objects to manage dialogue sequences as data. I needed a simple tool for quickly adding dialogue or interactions to different types of games, so I decided to make something lightweight for non-technical users.
It uses an IActor and IPanel interface to allow for dependency injection, letting you define any monobehaviour as an Actor that can be interacted with. It also includes basic interaction logic for a first person controller.
Here's a small example of it working in conjunction with a basic first person controller. The actor itself invokes a dialogue event that lets the dialogue manager know when to enable specific UI elements or images.
![Dialogue system example 1](/dialogue2.gif)

Dialogue is defined as scriptable data objects, allowing designers to write out dialogue and add portraits to a conversation without having to code.
Once a dialogue object is created, adding it is as simple as dragging it unto an Actor game object in the scene.
![Dialogue system example 2](/dialogue_data.png)

I want to move away from using the Unity editor for writing out scripts later on, possibly parsing a simple txt or JSON file containing the dialogue.

https://github.com/GarcGustavo/DungeonAutomata/tree/main/_Project/Scripts/DialogueSystem


Using Scriptable Objects to make a designer-friendly dialogue system.

Dialogue systems with Scriptable Objects

(Under construction)
A brief overview of some shaders I made to achieve a 2D doodle aesthetic with 3D lighting using Unity URP.

Crt example: ![Crt example](/crt.gif)
3D URP lighting on 2D sprites and doodle effect example: ![URP lighting example](/sprite_shading.gif)
Game of life compute shader example: ![Compute shader example](/compute.gif)

A brief overview of some shaders I made to achieve a 2D doodle aesthetic with 3D lighting using Unity URP.

Doodle displacement and lighting shaders.

(Under construction)
I created a basic game that utilizes cellular automata and binary space partitioning to procedurally create dungeon layouts.

(Main project repository)
https://github.com/GarcGustavo/DungeonAutomata

(Main generation script)
https://github.com/GarcGustavo/DungeonAutomata/blob/main/_Project/Scripts/Utilities/MapGenerator.cs

(An example of terrain mesh generation I made for an old programming language class project.)
https://github.com/GarcGustavo/PL_Project

Using cellular automata and Djikstra maps to generate/populate levels procedurally.

Procedural Generation and Djikstra maps

A small experiment using Unity's Cinemachine package to imitate Nier's camera/gameplay transitions.

Cinemachine for Rail Movement


(Under construction)

Road mesh generation example: ![Road mesh generation example](/curves.gif)


A small tool for generating roads and meshes from a set of points using Benzier curves.
